SOLAR EDGE SE8K Inverter – RWB48BFN4
SKU: F240R12
EAN: 5905951583716
| Manufacturer | |
|---|---|
| Rated power | |
| Power supply | |
| Hybrid device | |
| Warranty | |
| Net width | |
| Net depth | |
| Net height | |
| RS485 | |
| AFCI | |
| Weight | 37 kg |
Net price
1 922,86 €
Gross
Gross
Datasheet Solar Edge SE8K - RWB48BFN4
datasheet-solar-edge-se8k-rwb48bfn4.pdf
Product details
| Manufacturer | |
|---|---|
| Rated power | |
| Power supply | |
| Hybrid device | |
| Warranty | |
| Net width | |
| Net depth | |
| Net height | |
| RS485 | |
| AFCI | |
| Weight | 37 kg |
SolarEdge Inverters from the SE5K-RWB48, SE8K-RWB48, SE10K-RWB48 Series
The inverters from the SE5K-RWB48, SE8K-RWB48, SE10K-RWB48 series are advanced devices designed for managing photovoltaic energy production, energy storage, and providing emergency power. With their multifunctionality and reliability, they are the perfect choice for households that expect continuous power supply even in emergency situations.
Key Features:
- Simple Installation: One inverter manages photovoltaic production, energy storage, and operation during power outages, ensuring emergency power for the entire home.
- More Energy with DC Architecture: Direct energy storage in the battery minimizes losses associated with converting direct current to alternating current.
- Quick Startup: Configuration via the SolarEdge SetApp allows for a fast and easy device setup.
- Designed for Safety: The devices eliminate high voltage during installation, maintenance, and transport.
- Module-Level Monitoring: Full insight into battery status, photovoltaic production, and self-consumption energy use.
Why Choose Inverters from This Series?
The SE5K-RWB48, SE8K-RWB48, SE10K-RWB48 inverters are designed with flexibility and future expansion of the energy system in mind. They allow for the connection of SolarEdge energy storage and other suppliers, enhancing configuration possibilities and adapting to the changing needs of the user.
With advanced safety features and optimized energy management, these devices not only protect the installation but also maximize its efficiency. Ideal for installation in homes where reliability and effectiveness are key requirements.
Datasheet Solar Edge SE8K - RWB48BFN4
datasheet-solar-edge-se8k-rwb48bfn4.pdf
| Technical Data for SolarEdge SE5K – SE10K | ||||
|---|---|---|---|---|
| SE5K-RWB48 | SE8K-RWB48 | SE10K-RWB48 | ||
| OUTPUT – AC, GRID CONNECTION | ||||
| Rated Output Power [VA] | 5000 | 8000 | 10000 | |
| Maximum Output Power [VA] | 5000 | 8000 | 10000 | |
| Output Voltage AC – phase to phase / phase to neutral (rated voltage) [Vac] | 380/220; 400/230 | 380/220; 400/230 | 380/220; 400/230 | |
| AC – Output Voltage Range – phase to neutral [Vac] | 184 – 264.5 | 184 – 264.5 | 184 – 264.5 | |
| Frequency AC [Hz] | 50/60 ± 5 % | 50/60 ± 5 % | 50/60 ± 5 % | |
| Maximum Continuous Output Current (per phase) [A] | 8 | 13 | 16 | |
| Residual Current Detection/Step Residual Current Detection [mA] | 300 / 30 | 300 / 30 | 300 / 30 | |
| Supported Networks – Three-phase | 3 / N / PE (star network grounded at the neutral point with a neutral conductor) | 3 / N / PE (star network grounded at the neutral point with a neutral conductor) | 3 / N / PE (star network grounded at the neutral point with a neutral conductor) | |
| Network Monitoring, Islanding Protection, Configurable Power Factor, Configurable Threshold Values Based on Country | Yes | Yes | Yes | |
| OUTPUT – AC, EMERGENCY POWER | ||||
| Maximum Output Power [VA] | 4500 | 7200 | 9000 | |
| Output Voltage AC – phase to phase / phase to neutral (rated voltage) [Vac] | 380/220; 400/230 | 380/220; 400/230 | 380/220; 400/230 | |
| AC – Output Voltage Range – phase to neutral [Vac] | 184 – 264.5 | 184 – 264.5 | 184 – 264.5 | |
| Frequency AC [Hz] | 50/60 ± 5 % | 50/60 ± 5 % | 50/60 ± 5 % | |
| Maximum Continuous Output Current (per phase) [A] | 7.2 | 11.7 | 14.4 | |
| Residual Current Detection/Step Residual Current Detection [mA] | 300 / 30 | 300 / 30 | 300 / 30 | |
| Supported Networks – Three-phase | 3 / N / PE (star network grounded at the neutral point with a neutral conductor) | 3 / N / PE (star network grounded at the neutral point with a neutral conductor) | 3 / N / PE (star network grounded at the neutral point with a neutral conductor) | |
| Transformerless, Ungrounded | Yes | Yes | Yes | |
| Network Monitoring, Ensures Safe Disconnection from the Grid in Emergency Power Mode, Configurable Power Factor, Configurable Threshold Values Based on Country | Yes | Yes | Yes | |
| Automatic Switch-over Time [s] | <10 | <10 | <10 | |
| Maximum Allowed Phase Difference [kW] | 1.66 | 2.66 | 3 | |
| PV INPUT PARAMETERS | ||||
| Maximum DC Power (STC Module) [W] | 10000 | 13000 | 15000 | |
| Maximum Input Voltage [V DC] | 900 | 900 | 900 | |
| Nominal Input Voltage [V DC] | 750 | 750 | 750 | |
| Maximum Input Current [A DC] | 13.3 | 17.3 | 20 | |
| Reverse Polarity Protection | Yes | Yes | Yes | |
| Ground Fault Detection | Sensitivity 700 kΩ | Sensitivity 700 kΩ | Sensitivity 700 kΩ | |
| Maximum Inverter Efficiency [%] | 98 | 98 | 98 | |
| European Efficiency (weighted) [%] | 97.3 | 97.6 | 97.6 | |
| INPUT/OUTPUT – ENERGY STORAGE | ||||
| Supported Battery Types¹ | SolarEdge Home BAT-05K48 (1-5 battery modules), Firmware support coming soon for the following batteries: LG Chem RESU3.3, RESU6.5, RESU10, RESU12, RESU13, BYD Battery-Box Premium LVS 4.0, 8.0, 12.0, 16.0, 20.0, 24.0 Firmware support coming soon for the following batteries: BYD Battery-Box Premium LVS 4.0, 8.0, 12.0, 16.0, 20.0, 24.0 |
SolarEdge Home BAT-05K48 (1-5 battery modules), Firmware support coming soon for the following batteries: LG Chem RESU3.3, RESU6.5, RESU10, RESU12, RESU13, BYD Battery-Box Premium LVS 4.0, 8.0, 12.0, 16.0, 20.0, 24.0 Firmware support coming soon for the following batteries: BYD Battery-Box Premium LVS 4.0, 8.0, 12.0, 16.0, 20.0, 24.0 |
SolarEdge Home BAT-05K48 (1-5 battery modules), Firmware support coming soon for the following batteries: LG Chem RESU3.3, RESU6.5, RESU10, RESU12, RESU13, BYD Battery-Box Premium LVS 4.0, 8.0, 12.0, 16.0, 20.0, 24.0 Firmware support coming soon for the following batteries: BYD Battery-Box Premium LVS 4.0, 8.0, 12.0, 16.0, 20.0, 24.0 |
|
| Maximum Charging/Discharging Power [W] | 5000 | 5000 | 5000 | |
| Input Voltage Range [V DC] | 40-62 | 40-62 | 40-62 | |
| Maximum Continuous Input/Output Current [A DC] | 125 | 125 | 125 | |
| Maximum Efficiency of Discharging Storage to the Grid [%] | 96.1 | 96.1 | 96.1 | |
| Battery Communication with Inverter | CAN | CAN | CAN | |
| ADDITIONAL FEATURES | ||||
| Supported Communication Interfaces | Built-in: 2 x RS485, Ethernet, SolarEdge Home mesh network with antenna | Built-in: 2 x RS485, Ethernet, SolarEdge Home mesh network with antenna | Built-in: 2 x RS485, Ethernet, SolarEdge Home mesh network with antenna | |
| COMPLIANCE STANDARDS | ||||
| Safety | IEC62109 | IEC62109 | IEC62109 | |
| Grid Connection Standards² | VDE-AR-N 4105, Generator Type A, EN 50549-1, CEI 0-21, G98 Type A, G98 NI Type A, RD1699 / RD413 / NTS, VDE-V 0126-1-1, VFR 2019, C10/11, EN 50438 | VDE-AR-N 4105, Generator Type A, EN 50549-1, CEI 0-21, G98 Type A, G98 NI Type A, RD1699 / RD413 / NTS, VDE-V 0126-1-1, VFR 2019, C10/11, EN 50438 | VDE-AR-N 4105, Generator Type A, EN 50549-1, CEI 0-21, G98 Type A, G98 NI Type A, RD1699 / RD413 / NTS, VDE-V 0126-1-1, VFR 2019, C10/11, EN 50438 | |
| EMC | IEC61000-6-2, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12, EN55011 | IEC61000-6-2, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12, EN55011 | IEC61000-6-2, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12, EN55011 | |
| RoHS | Yes | Yes | Yes | |
| INSTALLATION PARAMETERS | ||||
| AC Output — Cable Gland Diameter [mm] | 15-21 | 15-21 | 15-21 | |
| Storage — Outer Diameter of Cable Gland [mm] | 2 x 11-16.5 | 2 x 11-16.5 | 2 x 11-16.5 | |
| DC PV Input | 2 pairs of MC4 | 2 pairs of MC4 | 2 pairs of MC4 | |
| Dimensions (h x w x d) [mm] | 907 x 317 x 192 | 907 x 317 x 192 | 907 x 317 x 192 | |
| Weight [kg] | 37 | 37 | 37 | |
| Operating Temperature Range [°C] | -40 to +60 | -40 to +60 | -40 to +60 | |
| Cooling | Internal and external fans | Internal and external fans | Internal and external fans | |
| Noise Emission [dBA] | < 50 | < 50 | < 50 | |
| Protection Class | IP65 – for outdoor and indoor use | IP65 – for outdoor and indoor use | IP65 – for outdoor and indoor use | |
| Mounting | Bracket included | Bracket included | Bracket included | |
